Deployment

Anjana Data offers different types of deployments:

  • On premise in the customer's data center.

  • Various types and models of cloud deployment (IaaS/PaaS), making use of the managed services offered by cloud providers.

  • As a SaaS service deployed on one of Anjana Data's Cloud subscriptions, including management by the Anjana Data team.

Anjana Data also provides an Ansible deployment kit that facilitates the implementation of the solution by having the installation and startup of each microservice that makes up the Anjana Data solution automated step by step.

For container-based deployments on K8S, Anjana Data provides a kit with the set of K8S statefulset and replicaset recipes.

Anjana Data also provides, for the deployment of the advanced monitoring system based on Grafana, a deployment kit to set up this system in an assisted manner.

SaaS Deployment Example

SAAS Standard Full.svg

SaaS Hybrid Deployment Example

SAAS Standard Hybrid.svg

k8s Deployment Example

https://lh7-rt.googleusercontent.com/docsz/AD_4nXcH0kaaHhZY6GEBHQNU5syQeasrQ44FO-qY5IDdpzHv5wiFT2IXzTdW8wy9m98G2ZfPaJu4E9yHVzokKSMt8RsVSwC_xdXzAwf4V8CFYGFdZ-WFv6nqowV_5Ulif1phYskaihSzc2f9tVtQ84sa8OPSetsJ?key=Tiwr4-tIyidEej616oBf5w

IaaS Deployment Example with Load Balancing

https://lh7-rt.googleusercontent.com/docsz/AD_4nXdvj_SeVSb6P3FUbXMHchvETKATnywLcxrQCaEgPPFEfrUAs0InuQA4iklZsHfgmY_V3IV8HNsFFdDwH4rbO175guYkC7O1lqdEU4FxGwbsC2-2ri64qVXt0W239IlAn9ogFJNuimz5bpvwLgCehHKUw5Y?key=Tiwr4-tIyidEej616oBf5w

Anjana Data provides different recommended configurations for Test, Base, Standard and Load Balanced environments, which allow the deployment to be adapted to different volumes of users and data.

These architectures are designed to ensure:

  • Proper load distribution.

  • Scalability and redundancy according to the criticality of the environment.

  • Integration with managed database and S3 storage services.

Test Infrastructure (POCs)

  • 1 VM - 8 VCore | 32 Gb RAM | 64Gb SSD



Base Infrastructure

  • 1 VM - 8 VCore | 32 Gb RAM | 64Gb SSD

  • Managed S3 - 64 Gb


Standard Infrastructure

  • 1VM (Core) - 4VCore | 16 Gb RAM | 64 Gb SSD

  • 1VM (Plugins) - 2VCore | 8Gb RAM | 32 Gb SSD

  • 1VM (Indexer) 2VCore | 4Gb RAM | 32 Gb SSD

  • Managed S3 - 128 Gb

  • Managed RDB - 2VCore | 2Gb RAM | 50Gb SSD

Note: Requirements for Ansible in case it is deployed on a separate VM with minimum requirements of 2vCPU | 4GB RAM | 32GB SSD



Balanced Infrastructure

  • 2VM (FrontBack) - 4VCore | 16 Gb RAM | 64 Gb SSD

  • 1VM (Plugins) - 2VCore | 8Gb RAM | 32 Gb SSD

  • 3VM (Indexer) - 2VCore | 4Gb RAM | 32 Gb SSD

  • Managed S3 HA - 128 Gb

  • Managed RDB HA - 4VCore | 4Gb RAM | 50Gb SSD



Machine for plugins (SaaS Hybrid mode)

It is recommended to perform a real estimate according to connectivity needs; at a minimum, 1 VM - 2VCore | 8Gb RAM | 32Gb SSD is recommended.
